Colson 125mm Blue Rubber Swivel Plate Brake I6 Series Castor 180kg
Colson 125mm Blue Rubber Swivel Plate Brake I6 Series Castor 180kg delivers a robust mobility solution for trade professionals. Engineered with a zinc plated steel housing and precision bearings, it provides smooth manoeuvrability on dual raceways with its blue elastic rubber wheels. The plate mount design and total brake ensure controlled movement, making it a practical choice for handling varied load requirements across both indoor and outdoor settings.
Couldn't load pickup availability
- Robust zinc plated steel housing offers lasting durability
- Blue elastic rubber wheel provides reliable traction
- Precision steel bearing enables smooth rotational movement
- Polyamide wheel core adds enhanced structural support
- Dual raceway design distributes load evenly for efficiency
- Total brake system ensures secure deceleration when required
- Plate mount fitting simplifies installation and maintenance procedures
- Reliable construction suited for indoor and outdoor applications
Product Data Sheet (Download PDF)
Specifications
| Outdoor Use | Yes |
| Indoor Use | Yes |
| Bearing Type | Precision Bearing |
| Raceway Type | Dual |
| Brake Type | Total |
Construction
| Wheel Core Material | Polyamide |
| Wheel Material | Blue Elastic Rubber |
| Housing Material | Zinc Plated Steel |
| Bearing Material | Steel |
| Product Colour | Silver/Blue |
Dimensions
| Product Length (mm) | 192 |
| Product Width (mm) | 85 |
| Product Height (mm) | 156 |
| Wheel Diameter (mm) | 125 |
| Tread Width (mm) | 40 |
| Swivel Radius (mm) | 140 |
| Mounting Hole Dimensions (mm) | 11.8x9 |
| Hole Centre Dimensions (LxW) mm | 82/78x62/58 |
| Plate Dimensions (LxW) mm | 104x85 |
Weights
| Product Weight (grams) | 1230 |
| Product Weight (kg) | 1.23 |
| Load Capacity (kg) | 180.0 |
