Easyroll 75mm Grey Urethane Swivel Plate Brake G7 Series Castor 80kg
Easyroll 75mm Grey Urethane Swivel Plate Brake G7 Series Castor 80kg is designed with a plate mount for straightforward installation in a variety of professional settings. It features a polyurethane wheel with a polypropylene core and stainless steel housing paired with ball bearings for smooth rotation. The castor offers a total brake and reliable plate swivel, providing durable support and precision for users requiring dependable mobility solutions in high-performance applications.
Couldn't load pickup availability
- Robust stainless steel 304 housing increases durability
- Polyurethane wheel design delivers improved traction and reduced wear
- Polypropylene wheel core reduces weight and improves stability
- Stainless steel ball bearings deliver smooth, reliable wheel rotation
- Total brake enables secure stopping with controlled motion
- Plate mount design provides sturdy installation and ease of fitting
- Swivel mechanism allows versatile wheel positioning and manoeuvring
- Distinct colour scheme aids visual identification of product components
Product Data Sheet (Download PDF)
Specifications
| Outdoor Use | Yes |
| Indoor Use | Yes |
| Bearing Type | Ball Bearing |
| Raceway Type | Single |
| Brake Type | Total |
| Attachments | Plate Swivel Total Brake |
Construction
| Wheel Core Material | Polypropylene |
| Wheel Material | Polyurethane |
| Housing Material | Stainless steel 304 |
| Bearing Material | Stainless Steel |
| Product Colour | Grey/Silver/Red |
Dimensions
| Product Length (mm) | 155 |
| Product Width (mm) | 70 |
| Product Height (mm) | 136 |
| Wheel Diameter (mm) | 100 |
| Tread Width (mm) | 32 |
| Swivel Radius (mm) | 107.5 |
| Mounting Hole Dimensions (mm) | 12.5x8.9 |
| Hole Centre Dimensions (LxW) mm | 74x48 |
| Plate Dimensions (LxW) mm | 95x70 |
Weights
| Product Weight (grams) | 604 |
| Product Weight (kg) | 0.604 |
| Load Capacity (kg) | 80.0 |
